Recommended Room Size
10-45 m²
Speaker Configuration
10 custom speaker drivers
4 x 4x3” Racetrack drivers
2 x 2” full range (front firing)
2 x 2” full range (side firing)
1 x 1,5” full range (up firing)
1 x 0,8” tweeter
Amplifier
10 power amplifiers:
4 x 70 watts amplifiers for woofers
1 x 50 watts amplifier for tweeter
5 x 50 watts amplifiers for left/right/up firing/side firing full ranges
Frequency Range
34 Hz - 23,000 Hz
Maximum Sound Pressure Level (SPL)
102 dB (SPL)
Bass Capability
86 dB (SPL)
Advanced Sound Features
Integrated 7.1.4 Dolby Atmos decoding and custom-tuned post-processing with proprietary True Image
up- / downmixing algorithm.
Wide Stage technology™
Advanced Bass management system Adaptive Bass Linearisation (ABL) Thermal protection
RoomSense
Manual speaker setup through the Bang & Olufsen App
Sound format HDMI
Dolby Atmos supporting
Dolby Digital TrueHD
Dolby Digital plus 7.1 (including DD5.1)
Dolby Atmos, Dolby MAT
PCM 7.1 multichannel
MPEG-2 AAC
MPEG-4 HE-AAC
Customizable Sound EQ
Presets available and fully customisable through the Bang & Olufsen App
